ZD4875
ZHIBI
RS232 CAN Open Remote Control 12-48vdc Intelligent Dual two Channel Bldc Motor Controller for AGV Robot
Intelligent brushless DC dual-motor controller. The brushless dual-motor driver can control two brushless DC motors at the same time. It adopts 32-bit high-performance MCU and advanced movement processing algorithm to realize internal electric differential function. The controller uses the Hall signal inside the motor as the rotor position feedback and works with the external incremental encoder (1000—2500 line) signal to control the movement of motor, realizing speed open-loop, close-loop modes, position mode and torque mode. It has two-way independent driver chip, two-way encoder processing chip, two-way Hall signal processing chip. Meanwhile, it has multiple failure alarm functions. It has two working modes: independent mode and mixed mode.
1) Power voltage: 10-55VDC. |
2) At the ambient temperature 25℃, continuous working current 30A, transient current up to 75A 30S. |
3) Minimum speed: 10 RPM in the speed close-loop mode; 1 RPM in the position mode. |
4) Out+5VDC power (It can power up the encoder): 5V DC 20mA |
5) Analog input range: 0-- 5VDC |
| 6) Impulse input range: 500Hz—5000Hz (corresponding maximum speed) [Note] The minimum impulse frequency may change along with the setting of maximum speed. |
| 7) Input range of duty ratio 0%-- 100% (input frequency range f ≤1KHz, recommend to use the frequency of 250Hz). |
| 8) Temperature protection status: When the temperature is 70℃, the controller will reduce output by overheating protection and will stop output when the temperature is 80℃. |
| 9) Working temperature: -20℃-- +60℃. |
| 10) Ambient humidity: Relative humidity≤80RH. |
| 11) Boundary dimension: L*W*H = 190mm*130mm*40mm |
| 12) Weight: 800g |
